Component carrier manager implementation which simply does nothing. More...

#include "simple-ue-component-carrier-manager.h"

Inheritance diagram for ns3::SimpleUeComponentCarrierManager:

Collaboration diagram for ns3::SimpleUeComponentCarrierManager:

Public Member Functions
	SimpleUeComponentCarrierManager ()
	Creates a No-op CCS algorithm instance. More...

virtual	~SimpleUeComponentCarrierManager ()

virtual LteMacSapProvider *	GetLteMacSapProvider ()
	Returns the MAC sap provider interface that if forwarding calls to the instance of the LteUeComponentCarrierManager. More...

Public Member Functions inherited from ns3::LteUeComponentCarrierManager
	LteUeComponentCarrierManager ()

virtual	~LteUeComponentCarrierManager ()

virtual LteUeCcmRrcSapProvider *	GetLteCcmRrcSapProvider ()
	Exports the "provider" part of the ComponentCarrier Management SAP interface. More...

bool	SetComponentCarrierMacSapProviders (uint8_t componentCarrierId, LteMacSapProvider *sap)
	Sets a pointer to SAP interface of MAC instance for the specified carrier. More...

virtual void	SetLteCcmRrcSapUser (LteUeCcmRrcSapUser *s)
	Set the "user" part of the ComponentCarrier Management SAP interface that this UE component carrier manager will interact with. More...

void	SetNumberOfComponentCarriers (uint8_t noOfComponentCarriers)
	Sets number of component carriers that are supported by this UE. More...

Public Member Functions inherited from ns3::Object
	Object ()
	Constructor. More...

virtual	~Object ()
	Destructor. More...

void	AggregateObject (Ptr< Object > other)
	Aggregate two Objects together. More...

void	Dispose (void)
	Dispose of this Object. More...

AggregateIterator	GetAggregateIterator (void) const
	Get an iterator to the Objects aggregated to this one. More...

virtual TypeId	GetInstanceTypeId (void) const
	Get the most derived TypeId for this Object. More...

template<>
Ptr< Object >	GetObject () const
	Specialization of () for objects of type ns3::Object. More...

template<typename T >
Ptr< T >	GetObject (TypeId tid) const
	Get a pointer to the requested aggregated Object by TypeId. More...

template<>
Ptr< Object >	GetObject (TypeId tid) const
	Specialization of (TypeId tid) for objects of type ns3::Object. More...

template<typename T >
Ptr< T >	GetObject (void) const
	Get a pointer to the requested aggregated Object. More...

void	Initialize (void)
	Invoke DoInitialize on all Objects aggregated to this one. More...

bool	IsInitialized (void) const
	Check if the object has been initialized. More...

Public Member Functions inherited from ns3::SimpleRefCount< Object, ObjectBase, ObjectDeleter >
	SimpleRefCount ()
	Default constructor. More...

	SimpleRefCount (const SimpleRefCount &o[[maybe_unused]])
	Copy constructor. More...

uint32_t	GetReferenceCount (void) const
	Get the reference count of the object. More...

SimpleRefCount &	operator= ([[maybe_unused]] const SimpleRefCount &o)
	Assignment operator. More...

void	Ref (void) const
	Increment the reference count. More...

void	Unref (void) const
	Decrement the reference count. More...

Public Member Functions inherited from ns3::ObjectBase
virtual	~ObjectBase ()
	Virtual destructor. More...

void	GetAttribute (std::string name, AttributeValue &value) const
	Get the value of an attribute, raising fatal errors if unsuccessful. More...

bool	GetAttributeFailSafe (std::string name, AttributeValue &value) const
	Get the value of an attribute without raising erros. More...

void	SetAttribute (std::string name, const AttributeValue &value)
	Set a single attribute, raising fatal errors if unsuccessful. More...

bool	SetAttributeFailSafe (std::string name, const AttributeValue &value)
	Set a single attribute without raising errors. More...

bool	TraceConnect (std::string name, std::string context, const CallbackBase &cb)
	Connect a TraceSource to a Callback with a context. More...

bool	TraceConnectWithoutContext (std::string name, const CallbackBase &cb)
	Connect a TraceSource to a Callback without a context. More...

bool	TraceDisconnect (std::string name, std::string context, const CallbackBase &cb)
	Disconnect from a TraceSource a Callback previously connected with a context. More...

bool	TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb)
	Disconnect from a TraceSource a Callback previously connected without a context. More...

Static Public Member Functions
static TypeId	GetTypeId ()
	Get the type ID. More...

Static Public Member Functions inherited from ns3::LteUeComponentCarrierManager
static TypeId	GetTypeId ()
	Get the type ID. More...

Static Public Member Functions inherited from ns3::Object
static TypeId	GetTypeId (void)
	Register this type. More...

Static Public Member Functions inherited from ns3::ObjectBase
static TypeId	GetTypeId (void)
	Get the type ID. More...

Protected Member Functions
virtual std::vector< LteUeCcmRrcSapProvider::LcsConfig >	DoAddLc (uint8_t lcId, LteUeCmacSapProvider::LogicalChannelConfig lcConfig, LteMacSapUser *msu)
	Add LC function. More...

virtual LteMacSapUser *	DoConfigureSignalBearer (uint8_t lcId, LteUeCmacSapProvider::LogicalChannelConfig lcConfig, LteMacSapUser *msu)
	Configure signal bearer function. More...

virtual void	DoDispose ()
	Destructor implementation. More...

virtual void	DoInitialize ()
	Initialize() implementation. More...

void	DoNotifyHarqDeliveryFailure ()
	Notify HARQ deliver failure. More...

void	DoNotifyTxOpportunity (LteMacSapUser::TxOpportunityParameters txOpParams)
	Notify TX opportunity function. More...

void	DoReceivePdu (LteMacSapUser::ReceivePduParameters rxPduParams)
	Receive PDU function. More...

std::vector< uint16_t >	DoRemoveLc (uint8_t lcid)
	Remove LC function. More...

virtual void	DoReportBufferStatus (LteMacSapProvider::ReportBufferStatusParameters params)
	Report buffer status function. More...

void	DoReportUeMeas (uint16_t rnti, LteRrcSap::MeasResults measResults)
	Report Ue Measure function. More...

void	DoReset ()
	Reset LC map. More...

void	DoTransmitPdu (LteMacSapProvider::TransmitPduParameters params)
	Transmit PDU function. More...

Protected Member Functions inherited from ns3::Object
	Object (const Object &o)
	Copy an Object. More...

virtual void	NotifyNewAggregate (void)
	Notify all Objects aggregated to this one of a new Object being aggregated. More...

Protected Member Functions inherited from ns3::ObjectBase
void	ConstructSelf (const AttributeConstructionList &attributes)
	Complete construction of ObjectBase; invoked by derived classes. More...

virtual void	NotifyConstructionCompleted (void)
	Notifier called once the ObjectBase is fully constructed. More...

Protected Attributes
LteMacSapProvider *	m_ccmMacSapProvider
	Receive API calls from the UE RLC instance. More...

LteMacSapUser *	m_ccmMacSapUser
	Interface to the UE RLC instance. More...

Protected Attributes inherited from ns3::LteUeComponentCarrierManager
LteUeCcmRrcSapProvider *	m_ccmRrcSapProvider
	Receive API calls from the UE RRC instance. More...

LteUeCcmRrcSapUser *	m_ccmRrcSapUser
	Interface to the UE RRC instance. More...

std::map< uint8_t, std::map< uint8_t, LteMacSapProvider * > >	m_componentCarrierLcMap
	Flow configuration per flow Id of this UE. More...

std::map< uint8_t, LteMacSapUser * >	m_lcAttached
	Map of pointers to SAP interfaces of the RLC instance of the flows of this UE. More...

std::map< uint8_t, LteMacSapProvider * >	m_macSapProvidersMap
	Map of pointers to SAP to interfaces of the MAC instance if the flows of this UE. More...

uint8_t	m_noOfComponentCarriers
	The number of component carriers that this UE can support. More...

Friends
class	MemberLteUeCcmRrcSapProvider< SimpleUeComponentCarrierManager >
	let the forwarder class access the protected and private members More...

class	SimpleUeCcmMacSapProvider
	allow SimpleUeCcmMacSapProvider class friend access More...

class	SimpleUeCcmMacSapUser
	allow SimpleUeCcmMacSapUser class friend access More...

Additional Inherited Members
Related Functions inherited from ns3::ObjectBase
static TypeId	GetObjectIid (void)
	Ensure the TypeId for ObjectBase gets fully configured to anchor the inheritance tree properly. More...

Detailed Description

Component carrier manager implementation which simply does nothing.

Selecting this component carrier selection algorithm is equivalent to disabling automatic triggering of component carrier selection. This is the default choice.

Config Paths

ns3::SimpleUeComponentCarrierManager is accessible through the following paths with Config::Set and Config::Connect:

"/NodeList/[i]/DeviceList/[i]/$ns3::LteNetDevice/$ns3::LteUeNetDevice/LteUeComponentCarrierManager/$ns3::SimpleUeComponentCarrierManager"
"/NodeList/[i]/DeviceList/[i]/$ns3::LteUeNetDevice/LteUeComponentCarrierManager/$ns3::SimpleUeComponentCarrierManager"

No Attributes are defined for this type.
No TraceSources are defined for this type.
Size of this type is 216 bytes (on a 64-bit architecture).

Definition at line 40 of file simple-ue-component-carrier-manager.h.

Constructor & Destructor Documentation

◆ SimpleUeComponentCarrierManager()

ns3::SimpleUeComponentCarrierManager::SimpleUeComponentCarrierManager ( )

Creates a No-op CCS algorithm instance.

Definition at line 131 of file simple-ue-component-carrier-manager.cc.

References m_ccmMacSapProvider, m_ccmMacSapUser, ns3::LteUeComponentCarrierManager::m_ccmRrcSapProvider, MemberLteUeCcmRrcSapProvider< SimpleUeComponentCarrierManager >, NS_LOG_FUNCTION, SimpleUeCcmMacSapProvider, and SimpleUeCcmMacSapUser.

◆ ~SimpleUeComponentCarrierManager()

ns3::SimpleUeComponentCarrierManager::~SimpleUeComponentCarrierManager ( )

virtual

Definition at line 140 of file simple-ue-component-carrier-manager.cc.

References NS_LOG_FUNCTION.

Member Function Documentation

◆ DoAddLc()

std::vector< LteUeCcmRrcSapProvider::LcsConfig > ns3::SimpleUeComponentCarrierManager::DoAddLc	(	uint8_t	lcId,
		LteUeCmacSapProvider::LogicalChannelConfig	lcConfig,
		LteMacSapUser *	msu
	)

protectedvirtual

Add LC function.

Parameters

lcId	the LCID
lcConfig	the logical channel config
msu	the MSU

Returns: updated LC config list

Definition at line 305 of file simple-ue-component-carrier-manager.cc.

References ns3::LteUeCcmRrcSapProvider::LcsConfig::componentCarrierId, ns3::LteUeCcmRrcSapProvider::LcsConfig::lcConfig, m_ccmMacSapUser, ns3::LteUeComponentCarrierManager::m_componentCarrierLcMap, ns3::LteUeComponentCarrierManager::m_lcAttached, ns3::LteUeComponentCarrierManager::m_macSapProvidersMap, ns3::LteUeComponentCarrierManager::m_noOfComponentCarriers, ns3::LteUeCcmRrcSapProvider::LcsConfig::msu, NS_ABORT_MSG_IF, and NS_LOG_FUNCTION.

◆ DoConfigureSignalBearer()

LteMacSapUser * ns3::SimpleUeComponentCarrierManager::DoConfigureSignalBearer	(	uint8_t	lcId,
		LteUeCmacSapProvider::LogicalChannelConfig	lcConfig,
		LteMacSapUser *	msu
	)

protectedvirtual

Configure signal bearer function.

Parameters

lcId	the LCID
lcConfig	the logical channel config
msu	the MSU

Returns: LteMacSapUser *

Definition at line 341 of file simple-ue-component-carrier-manager.cc.

References m_ccmMacSapUser, ns3::LteUeComponentCarrierManager::m_componentCarrierLcMap, ns3::LteUeComponentCarrierManager::m_lcAttached, ns3::LteUeComponentCarrierManager::m_macSapProvidersMap, ns3::LteUeComponentCarrierManager::m_noOfComponentCarriers, NS_ABORT_MSG_IF, and NS_LOG_FUNCTION.

◆ DoDispose()

void ns3::SimpleUeComponentCarrierManager::DoDispose ( void )

protectedvirtual

Destructor implementation.

This method is called by Dispose() or by the Object's destructor, whichever comes first.

Subclasses are expected to implement their real destruction code in an overridden version of this method and chain up to their parent's implementation once they are done. i.e, for simplicity, the destructor of every subclass should be empty and its content should be moved to the associated DoDispose() method.

It is safe to call GetObject() from within this method.

Reimplemented from ns3::LteUeComponentCarrierManager.

Definition at line 147 of file simple-ue-component-carrier-manager.cc.

References m_ccmMacSapProvider, m_ccmMacSapUser, ns3::LteUeComponentCarrierManager::m_ccmRrcSapProvider, and NS_LOG_FUNCTION.

◆ DoInitialize()

void ns3::SimpleUeComponentCarrierManager::DoInitialize ( void )

protectedvirtual

Initialize() implementation.

This method is called only once by Initialize(). If the user calls Initialize() multiple times, DoInitialize() is called only the first time.

Subclasses are expected to override this method and chain up to their parent's implementation once they are done. It is safe to call GetObject() and AggregateObject() from within this method.

Reimplemented from ns3::Object.

Definition at line 176 of file simple-ue-component-carrier-manager.cc.

References ns3::Object::DoInitialize(), and NS_LOG_FUNCTION.

Here is the call graph for this function:
